| تصویر | مدل | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
EPA 50-30ZA | 50 | 20 | 25 | 30 | 380 | 50 | 3000 | 321.5 | Chuck |
 |
EPA 25-23ZD | 25 | 3 | 21 | 23 | 24 | / | 380 | 170 | Chuck |
 |
EPA 25-23ZAX | 25 | 3 | 21 | 23 | 220 | 50/60 | 440 | 168 | Chuck |
 |
EPA 25-23ZA | 25 | 3 | 21 | 23 | 220 | 50/60 | 440 | 208 | Chuck |
 |
EPA 25-20ZA | 25 | 3 | 17 | 20 | 250 | 50/60 | 350 | 208 | Chuck |
|
EPA 25-20ZAX | 25 | 3 | 16 | 20 | 270 | 50 | 350 | 168 | Chuck |
 |
Master H 20-9 Pro | 20 | 2.5 | 6.5 | 9 | 220~240 | 50/60 | 95 | 130 | G 1 |
 |
Master H 25-7.5 Pro | 25 | 2.2 | 4.7 | 7.5 | 220~240 | 50/60 | 60 | 130/180 | G 1 1/2 |
