| تصویر | مدل | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
Basic 32-9F | 32 | 5 | 6.5 | 9 | 115/230 | 50/60 | 300 | 180/220 | G2 |
 |
Basic 32-9 | 32 | 5 | 6.5 | 9 | 115/230 | 50/60 | 300 | 180/220 | G2 |
 |
Basic 50-12F Pro | 50 | 16 | 8 | 12 | 220~240 | 50 | 1000 | 280 | DN50 |
 |
Basic 25-16S | 25 | 7 | 12.5 | 16 | 380 | 50 | 700 | 230 | G1 1/2 |
 |
Basic 32-20S | 32 | 9 | 14 | 20 | 380 | 50 | 1000 | 230 | G2 |
 |
Basic 65-15SF Pro | 65 | 20 | 12 | 15 | 380 | 50 | 1500 | 340 | DN65 |
|
Basic 65-12SF Pro | 65 | 20 | 10.7 | 13 | 380 | 50 | 1300 | 340 | DN65 |
 |
Basic 80-12SF Pro | 80 | 25 | 10 | 12 | 380 | 50 | 1500 | 360 | DN80 |
