| تصویر | مدل | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
AWZ65-40-200 | 65 | 48 | 46 | 40 | 380 | 50 | 5500 | 501 | Chuck |
|
AWZ65-40-160 | 65 | 25 | 40 | 37.5 | 380 | 50 | 4000 | 557 | Chuck |
 |
EPA25-37NC | 25 | 15 | 30 | 37 | 220 | 50/60 | 1000 | 393 | Chuck |
 |
EPS25-40NC | 25 | 6 | 30 | 42 | 380 | 50 | 1300 | 393 | Chuck |
|
EPS25-30NC | 25 | 5 | 25 | 30 | 380 | 50 | 1000 | 359 | Chuck |
 |
EPA 50-45ZAX | 50 | 42 | 30 | 45 | 380 | 50 | 6000 | 303 | Chuck |
|
EPA 50-45ZA | 50 | 42 | 30 | 45 | 380 | 50 | 6000 | 303 | Chuck |
 |
EPA 50-40ZAX | 50 | 30 | 30 | 40 | 380 | 50 | 5500 | 303 | Chuck |
|
EPA 50-40ZAX | 50 | 30 | 30 | 40 | 380 | 50 | 5500 | 303 | Chuck |
 |
EPA 50-30ZAX | 50 | 30 | 20 | 35 | 380 | 50 | 3300 | 274.8 | Chuck |
|
EPA 50-30ZA | 50 | 30 | 20 | 35 | 380 | 50 | 3300 | 274.8 | Chuck |
 |
EPA 50-30ZAX | 50 | 20 | 25 | 30 | 380 | 50 | 3000 | 274.8 | Chuck |
 |
EPA 50-30ZA | 50 | 20 | 25 | 30 | 380 | 50 | 3000 | 321.5 | Chuck |
 |
EPA 25-23ZD | 25 | 3 | 21 | 23 | 24 | / | 380 | 170 | Chuck |
 |
EPA 25-23ZAX | 25 | 3 | 21 | 23 | 220 | 50/60 | 440 | 168 | Chuck |
 |
EPA 25-23ZA | 25 | 3 | 21 | 23 | 220 | 50/60 | 440 | 208 | Chuck |
 |
EPA 25-20ZA | 25 | 3 | 17 | 20 | 250 | 50/60 | 350 | 208 | Chuck |
|
EPA 25-20ZAX | 25 | 3 | 16 | 20 | 270 | 50 | 350 | 168 | Chuck |
 |
Mega S 32-12 Pro | 32 | 5.5 | 7.5 | 12 | 220~240 | 50/60 | 220 | 180 | G2 |
 |
Mega S 25-12 Pro | 25 | 5.5 | 7.5 | 12 | 220~240 | 50/60 | 220 | 180 | G1 1/2 |
 |
Mega S 32-12F Pro | 32 | 11 | 7 | 12 | 220~240 | 50/60 | 400 | 180 | G2 |
 |
Grand 32-17 Pro | 32 | 5 | 12 | 17 | 220~240 | 50/60 | 350 | 180 | G 2 |
 |
Grand 25-17 Pro | 25 | 5 | 12 | 17 | 220~240 | 50/60 | 350 | 180 | G 1 1/2 |
 |
Grand 32-15 Pro | 32 | 5.5 | 11 | 15 | 220~240 | 50/60 | 300 | 180 | G2 |
 |
Grand 25-15 Pro | 25 | 5.5 | 11 | 15 | 220~240 | 50/60 | 300 | 180 | G 1 1/2 |
 |
Grand 32-13 Pro | 32 | 4 | 8 | 13 | 220~240 | 50/60 | 195 | 180 | G2 |
 |
Grand 25-13 Pro | 25 | 4 | 8 | 13 | 220~240 | 50/60 | 195 | 130/180 | G 1 1/2 |
 |
Grand 32-11 Pro | 32 | 3.5 | 8 | 11 | 220~240 | 50/60 | 160 | 180 | G2 |
 |
Master H 20-9 Pro | 20 | 2.5 | 6.5 | 9 | 220~240 | 50/60 | 95 | 130 | G 1 |
 |
Master H 25-7.5 Pro | 25 | 2.2 | 4.7 | 7.5 | 220~240 | 50/60 | 60 | 130/180 | G 1 1/2 |
